M4 Max

Simultaneous support for up to five displays:

• Up to four displays with 6K resolution at 60Hz over Thunderbolt and one display with 4K resolution at 144Hz over HDMI
• Up to two displays with 6K resolution at 60Hz over Thunderbolt and one display with 8K resolution at 60Hz or 4K resolution at up to 240Hz over HDMI

M3 Ultra

Simultaneous support for up to eight displays:

• Eight displays with up to 6K resolution at 60Hz or 4K resolution at up to 144Hz
• Four displays with up to 8K resolution at 60Hz or 4K resolution at up to 240Hz

Thunderbolt 5 digital video output

• Support for native DisplayPort 2.1 output over USB‑C

HDMI display video output

• Support for one display with up to 8K resolution at 60Hz or 4K resolution at 240Hz
• Support for variable refresh rate (VRR), HDR and multi-channel audio

• Built-in speaker
• 3.5 mm headphone jack with advanced support for high-impedance headphones
• HDMI port supports multichannel audio output

Wi-Fi

• Wi-Fi 6E (802.11ax)²

Bluetooth

• Bluetooth 5.3

Ethernet

• 10Gb Ethernet (Nbase-T Ethernet with support for 1Gb, 2.5Gb, 5Gb, and 10Gb Ethernet using RJ-45 connector)

• Line voltage: 100V to 240V AC
• Frequency: 50Hz to 60Hz, single phase
• Maximum continuous power: 480W
• Operating temperature: 10° to 35° C
• Storage temperature: –40° to 47° C
• Relative humidity: 5% to 95% non-condensing
• Operating altitude: tested up to 5,000 metres

Accessibility features help people with disabilities get the most out of their new Mac Studio. With built-in support for vision, hearing, mobility and learning, you can create and do amazing things.

Learn more

Features include:

• 100% recycled aluminium in the enclosure and thermal module chassis
• 100% recycled copper in multiple printed circuit boards
• 100% recycled gold in the plating of all Apple-designed printed circuit boards and all connectors
• 100% recycled rare earth elements in all magnets
• 100% recycled tin in the solder of multiple printed circuit boards
• 100% recycled copper and zinc in the prongs of the power cable plug and AC inlet
• At least 25% recycled plastic in three components
• 100% fibre-based packaging¹¹
• 59% recycled content in fibre-based packaging

Learn more

• Mac Studio is designed to reduce environmental impact:⁷

  See the Mac Studio Product Environmental Report (PDF)

  Progress towards Apple 2030

  • More than 30% recycled content⁸
  • Over 35% of manufacturing electricity sourced from low-carbon electricity⁹
  • Over 30% emissions reduction against business-as-usual scenario as modelled by Apple¹⁰

  See Apple’s commitment

• Energy

  • Over 35% of manufacturing electricity for Mac Studio is sourced from low-carbon electricity
  • ENERGY STAR® certified¹²

  Waste

  • No established final assembly sites generate waste sent to landfill as part of Apple’s Zero Waste Programme

• Height: 3.7 inches (9.5 cm)
• Width: 7.7 inches (19.7 cm)
• Depth: 7.7 inches (19.7 cm)

• Mac Studio
• Power cord
